Answer the question with hardware.
Prototype loops that settle arguments — printed, machined or fabricated parts built to test one thing at a time, with every measured result fed back into the model and the cost sheet.
SOLIDWORKSFUSION 360ANSYSMAGICSKEYSHOT
++
FIG.132 — BATTERY BOX PROTO · REV.5
CLICK TO EXPLODE / ASSEMBLE
BATTERY BOX PROTOREV.5FIG.132SLS NYLON · PRINTED HINGESCALE SCALE 1:2SHT 1/3
SVC.02.C — PROTOTYPE INDEX, EIGHT LINES
Build it, break it,
then draw it properly
EVERY LOOP DOCUMENTED AND FED BACK INTO THE MODEL — SLA, SLS, FDM, CNC AND FABRICATION
.01Value Engineering & Cost TeardownsA line-by-line teardown of what each part costs against what it earns — anything failing that test is removed, combined or re-specified.
.02SLA, SLS & FDM Prototype PreparationGeometry adapted for the printing process — wall thickness, clearances, orientation and supports resolved before the file leaves us.
.03CNC & Fabricated Prototype PartsMachined and fabricated prototypes when stiffness, temperature or real material properties matter more than turnaround.
.04Functional & Fit Test RigsPurpose-built rigs and fixtures that load the part the way service will, so results mean something outside the lab.
.05Test Plans & Instrumented TrialsA written test plan before the build — what is measured, at what tolerance and what counts as a pass.
.06Mechanism Proving & Life TestingHinges, latches and linkages cycled to a defined count, with failure modes photographed and logged rather than explained away.
.07Bridge & Soft ToolingSilicone tools, aluminium bridge tools and short-run inserts that cover pilot volumes while production tooling is cut.
.08Iteration Control & Revision LogsEvery loop revision-controlled, with a cost delta attached to each change so the improvement is visible in money.
PROCESS — FOUR CHECKPOINTS
How a prototype earns its cost
STEP.01
Define the question
Each prototype answers something specific — fit, stiffness, seal, ergonomics or cost. Parts that answer nothing do not get built.
STEP.02
Build & source
Geometry prepared for the right process — SLA for detail, SLS for function, CNC for stiffness — and quoted through vetted suppliers.
STEP.03
Test & record
Trials run to the written test plan, with measured results, photographs and failures recorded as they happened.
STEP.04
Fold back into CAD
Findings applied to the model under revision control with a cost delta per change — then the next loop, or release.
SECTORS —MEDICAL DEVICESCONSUMER PRODUCTSINDUSTRIAL EQUIPMENTINSTRUMENTATIONROBOTICSAUTOMOTIVECLEANTECH
Prototypes we've put on the bench
ALL WORK →DROP RENDER — FIG.64
BATTERY BOX PRINTED PROTOFIG.64
DROP RENDER — FIG.65
SLS HOUSING FIT TRIALFIG.65
DROP RENDER — FIG.66
SEAL COMPRESSION TEST RIGFIG.66
DROP RENDER — FIG.67
HINGE LIFE-CYCLE FIXTUREFIG.67
DROP RENDER — FIG.68
MACHINED MANIFOLD MULEFIG.68
DROP RENDER — FIG.69
SOFT-TOOLED BEZEL BATCHFIG.69
OUR CLIENTS — ON THE RECORD
Signed off, worldwide
REG.014 — SIGN-OFF
“Very well thought out and articulate communication. Clear milestones, deadlines and fast work. No shortcuts. The best part — always solving problems with great original ideas.”
COURTNEY HENRYCUSTOMER IN U.S.A
ORIGINUSASERVICERAPID PROTOTYPINGSTATUSAPPROVED ✓
SHT 1 / 3
RFI LOG — MOST FREQUENT QUESTIONS
Before you ask
We prepare and validate the geometry, then place it with vetted SLA, SLS, FDM and CNC suppliers in the UK, USA and Australia. You see the quotes.
Need hardware in hand
before the next decision?
NDA-FIRST · SCOPED WITHIN 24H · NAMED ENGINEER
