How do you manage store variants?

One master fixture with a dimensioned variant schedule. Each store type gets its own pack, and all of them share a single revision history.

What materials do you specify for retail work?

Typically 19mm MDF carcasses with HPL laminate faces, solid surface tops and painted or veneered feature panels, always to your brand standard.

Do you provide visuals for client approval?

Yes. KeyShot renders are produced from the same model as the drawings, so the approved image and the manufactured fixture cannot diverge.

Can you detail flat-pack fixtures?

Yes, knock-down fittings, assembly sequences and site instructions are drawn so units ship flat and assemble without specialist tools.

How do you keep rollout costs down?

Standard panel sizes, batch nesting and components shared across variants. Material usage is reported per sheet so the saving is visible, not claimed.

INDEX / SVC.03 JOINERY / SVC.03.C · RETAIL FIXTURES

Fixtures built to repeat, store after store.

Display units, counters and rollout fixture packages engineered for repeat manufacture, one drawing set that survives a hundred builds and a dozen store variants without drifting.

Get in touch What we engineer →
