Which construction system do you draw to?

The 32mm system by default, on 19mm MDF or birch ply. If your workshop has its own construction standard, we draw to that instead.

Can you match our existing hardware library?

Yes. Send your Blum, Hafele or Hettich part list and it becomes the schedule, no substitutions are made without asking first.

Are appliance clearances your responsibility?

We dimension apertures and services from the appliance manufacturer's data sheets and mark every assumption on the drawing for you to confirm.

What CNC outputs do you supply?

Nested DXFs with hinge, dowel and shelf-pin drilling applied, plus labelled cut lists, output for your nesting or point-to-point machine.

How are revisions handled?

Every issue carries a revision letter and a change note, and superseded sheets are clouded, so the workshop never cuts from an old drawing.

INDEX / SVC.03 JOINERY / SVC.03.B · RESIDENTIAL CABINETRY

Kitchens and wardrobes, resolved to the millimetre.

Carcass drawings, front elevations and machine-ready panel files for kitchens, wardrobes and built-ins, appliance clearances, services and site conditions worked out before the saw runs.

Get in touch What we draw →

SWOODSOLIDWORKSPOLYBOARDCABINET VISIONAUTOCAD

ISSUED TOISOASMEDINBS

ON YOUR TEMPLATES
AND TITLE BLOCKS

FIG.82 · WARDROBE RUN · REV.2

CLICK TO EXPLODE / ASSEMBLE

WARDROBE RUNREV.2FIG.82OAK VENEER · 19MM MDFSCALE 1:20SHT 1/8

SVC.03.B · CABINETRY INDEX, SEVEN LINES

Drawn once,
cut once

CARCASS, FRONTS, HARDWARE AND SERVICES · ALL ON THE SAME SET OF SHEETS

.01Kitchen & Utility Carcass SetsBase, wall and tall units drawn on the 32mm system in 19mm MDF or birch ply, with one construction standard across the whole run.

.02Wardrobe & Built-in Storage RunsFitted runs set out against real wall dimensions, fillers, scribes and end panels sized so the run closes cleanly at both ends.

.03Front Elevations & Reveal Setting-OutDoor and drawer faces set out with consistent 3mm reveals, alignment carried across the full elevation and around corners.

.04Appliance & Services CoordinationApertures, sockets, waste runs and extract paths dimensioned from the manufacturer's data sheets, not from memory.

.05Runners, Hinges & Lift System SchedulesBlum TANDEMBOX, Hafele hinges and Hettich lift systems scheduled, with drilling positions marked on the panel drawing.

.06CNC Panel Files & NestingNested DXFs with dowel, hinge and shelf-pin drilling applied, panels labelled to match the cut list line for line.

.07Cut Lists, Edge Banding & Take-OffsBoard counts, banding lengths and finished sizes issued per job, so purchasing and the workshop read the same numbers.

PROCESS · FOUR CHECKPOINTS

How a kitchen reaches the workshop

STEP.01

Survey & brief

Room dimensions, services, appliance schedule and the designer's layout collected before any carcass is drawn.

STEP.02

Fixed quote

A written quote inside 24 hours covering sheet count, CNC outputs and the revision allowance.

STEP.03

Layout sign-off

Plans and front elevations issued for approval first, nothing is detailed until the layout is agreed.

STEP.04

Manufacture pack

Carcass drawings, cut lists, hardware schedules and nested files issued together, checked by a second detailer.

SECTORS ·RESIDENTIALKITCHEN STUDIOSFIT-OUT & INTERIORSPROPERTY DEVELOPERSFURNITURE MAKERSARCHITECTURAL JOINERYHOSPITALITY

Cabinetry we've detailed

ALL WORK →

RESIDENTIAL KITCHENFIG.82

KITCHEN ISLANDFIG.83

WARDROBEFIG.84

VANITY UNITFIG.85

WALK-IN CLOSETFIG.86

FITTED KITCHENFIG.87
